INFUSE™ CS-100 Core Sensing Module

Solid-state gas sensor designed for simplicity

The core sensing chip — a miniature MEMS hydrogen sensor for integration into gas and oil-phase measurement systems. Available for OEM integration.

Other instruments

SENSOR

INFUSE™ CS-100 Core Sensing Module

At the heart of the system is a compact MEMS-based hydrogen sensing chip, designed for seamless integration into gas and oil-phase measurement platforms. Its small form factor and low power consumption make it ideal for OEM applications, enabling manufacturers to embed high-sensitivity hydrogen detection directly into their systems. Built for scalability and adaptability, it supports next-generation sensing solutions across energy, industrial, and mobility applications.

Headline Features

  • Fast hydrogen detection with high sensitivity
  • Low power consumption, suitable for embedded systems
  • Wide operating hydrogen concentration range
  • High selectivity against common interfering gases (CH₄, CO₂)
  • Compact, robust package for industrial environments
  • Compatible with external digital or analog readout electronics
Pre-Order
Request Technical Brief

Technical Specifications

Detection & Performance

  • Chip Dimension
  • 3mm (L) × 4mm (W) × 0.5mm (T)
  • Sensor Dimension
  • < 8 cm²
  • Weight
  • 1 g
  • Sensors per Chip
  • 4
  • Applied Voltage Range
  • 0.5–2.5 V
  • Target Gas
  • Hydrogen (H₂)
  • Concentration Range
  • 0 to 99.99% vol H₂
  • Environment
  • Gas and oil phase available
  • Repeatability
  • < 50 ppm (up to 5%), < 300 ppm (up to 20%), < 0.1% rest
  • Detection Limit
  • 15 ppm H₂ (in oil) / 30 ppm H₂ (in gas)
  • Quantification Limit
  • 30 ppm H₂ (in oil) / 60 ppm H₂ (in gas)
  • Response Time (T90)
  • < 10 min (in oil) / 10 sec (in gas)

Environmental Specifications

  • Operating Temperature
  • -20 °C to +150 °C
  • Storage Temperature
  • -20 °C to +150 °C
  • Pressure
  • Up to 20 bar (in gas)

Electrical Characteristics

  • Supply Power
  • 2.7 to 30V (9 or 12 recommended)
  • Communication (Wire)
  • 4-20 mA, RS-485, Modbus
  • Communication (Wireless)
  • BLE and WiFi
  • Certification
  • ATEX, EC, and more by client request

Applications

Delivering reliable performance even in the most demanding environments.

  • Process Control
  • Utility Transformer

Ready to Get Started?

Pre-order your unit or request a technical brief from our engineering team.

Pre-Order

3D Model — Coming Soon
