BD-IOO Battery Leak Detector

  • #Hydrogen
  • #Sensor
  • #Instrument
  • #H2Detection

H2FAST™ BD-100 Battery Leak Detector

Deliver continuous, fast detection of hydrogen (H₂) and battery off-gases, and are purpose-built for use in data centers and battery rooms.

Ultra-compact 12 mm × 12 mm hydrogen leak detector designed for battery safety. Real-time ppm-level detection of hydrogen off-gassing for early warning of thermal events in battery systems.

Other instruments

Clip-on Leak Detector

Headline Features

  • Fast hydrogen detection with high sensitivity
  • Ultra-compact 12 mm × 12 mm form factor for embedded battery applications
  • Low power consumption, suitable for embedded BMS integration
  • Wide operating hydrogen concentration range (and humidity range)
  • High selectivity against common interfering gases (CH₄, CO₂)
  • Compatible with external digital or analog readout electronics
Pre-Order
Request Technical Brief

Technical Specifications

Detection & Performance

  • Target Gas
  • Hydrogen (H₂)
  • Detection Range
  • Typical 200–50,000 ppm (testing ppb)
  • Linearity
  • Linear up to 50,000 ppm
  • Repeatability
  • 50 ppm
  • Auxiliary Sensors
  • Temperature & Humidity sensor
  • Sensitivity Resolution
  • ~ 50 ppm or 0.05% of the reading
  • Response Time (T90)
  • < 60 s (projected < 3 s)
  • Dimensions
  • 12 mm × 12 mm

Environmental Specifications

  • Operating Temperature
  • 0 °C to +80 °C
  • Storage Temperature
  • -20 °C to +85 °C
  • Operating Humidity
  • Up to 95% RH, non-condensing
  • Pressure
  • Atmospheric pressure (<100 mbar)

Electrical Characteristics

  • Supply Power (RS-485)
  • 12 V
  • Supply Power (Equipment)
  • 2.7 to 30 V (9V or 12V recommended)
  • Power Consumption (Average)
  • < 0.05 W
  • Power Consumption (Peak)
  • < 0.1 W

Applications

Delivering reliable performance even in the most demanding environments.

  • Battery Safety
  • Battery Rooms
  • Energy Storage Systems
  • EV Battery Packs
  • Data Center UPS

Ready to Get Started?

Pre-order your unit or request a technical brief from our engineering team.

Pre-Order
Download Whitepaper

3D Model — Coming Soon
