Emission Free High Pressure
Gas Probe Sensor
*
In-line hydrogen gas probe sensor for high-pressure applications up to 10 bar. Explosion-proof certified with process connection options.
In-line
Scroll to explore
Emission Free High Pressure Gas Probe Sensor delivers Process Control* grade precision
Fast hydrogen detection with high sensitivity
Low power consumption, suitable for embedded systems
High selectivity against common interfering gases (CH₄, CO₂)
Compact, robust package for industrial environments
Compatible with external digital or analog readout electronics
In-line hydrogen gas probe sensor for high-pressure applications up to 10 bar. Explosion-proof certified with process connection options.
Fast hydrogen detection with high sensitivity
Technical Specifications
Target Gas
Target Gas
Hydrogen (H₂)
Detection Range
Typical
0.1-99.9 % vol H₂
Repeatability
< 5%
Sensitivity
Detection limit
0.5 % H2 vol. (projected 50 ppm)
Quantification limit
0.1 % H2 vol. (projected 150 ppm)
Response Time (T90)
10 sec (projected < 3 s)
Environmental Specifications
Operating Temperature
0 °C to +80 °C
Storage Temperature
-20 °C to +85 °C
Pressure
up to 10 bar
Electrical Characteristics
Supply power (RS-845)
12 V
Supply power (Equipment)
2.7 to 30 V (9V or 12 V recommended)
Power Consumption
Average
< 0.05 W
Peak
< 0.1 W
Fast hydrogen detection with high sensitivity
Low power consumption, suitable for embedded systems
High selectivity against common interfering gases (CH₄, CO₂)
Compact, robust package for industrial environments
Compatible with external digital or analog readout electronics
Engineered for precision
*Built from deep research and field expertise to deliver the accuracy and reliability your operations demand.
ANALYZER Technology
Designed for Process Control*, Utility Transformer applications. Delivering reliable performance even in the most demanding environments.
System Configuration
Select your required specifications to configure this production unit
In-line hydrogen gas probe sensor for high-pressure applications up to 10 bar. Explosion-proof certified with process connection options.
