Product Details
Leak Detector
H2FAST™ BD-100 Battery
Leak Detector
*
Ultra-compact 12 mm × 12 mm hydrogen leak detector designed for battery safety. Real-time ppm-level detection of hydrogen off-gassing for early warning of thermal events in battery systems.
Scroll to explore
H2FAST™ BD-100 Battery Leak Detector delivers Energy Storage grade precision
Fast hydrogen detection with high sensitivity
Ultra-compact 12 mm × 12 mm form factor for embedded battery applications
Low power consumption, suitable for embedded BMS integration
Wide operating hydrogen concentration range (and humidity range)
High selectivity against common interfering gases (CH₄, CO₂)
Compatible with external digital or analog readout electronics
Ultra-compact 12 mm × 12 mm hydrogen leak detector designed for battery safety. Real-time ppm-level detection of hydrogen off-gassing for early warning of thermal events in battery systems.
Fast hydrogen detection with high sensitivity
Technical Specifications
Target Gas
Target Gas
Hydrogen (H₂)
Detection Range
Typical
200-50,000 ppm l H₂ (projected 50 ppm)
Linearity
Linear up to 50,000 ppm
Repeatability
0.01% or 50 ppm
Auxiliary sensors
Auxiliary Sensors
Temperature & Humidity sensor
Sensitivity
Resolution
~ 50 ppm or 0.05% of the reading
Response Time (T90)
< 60 s (projected < 3 s)
Dimensions
12 mm × 12 mm
Environmental Specifications
Operating Temperature
0 °C to +80 °C
Storage Temperature
-20 °C to +85 °C
Operating Humidity
Up to 95% RH, non-condensing
Pressure
Atmospheric pressure (<100 mbar)
Electrical Characteristics
Supply power (RS-845)
12 V
Supply power (Equipment)
2.7 to 30 V (9V or 12 V recommended)
Power Consumption
Average
< 0.05 W
Peak
< 0.1 W
Fast hydrogen detection with high sensitivity
Ultra-compact 12 mm × 12 mm form factor for embedded battery applications
Low power consumption, suitable for embedded BMS integration
Wide operating hydrogen concentration range (and humidity range)
High selectivity against common interfering gases (CH₄, CO₂)
Compatible with external digital or analog readout electronics
Engineered for precision
*Built from deep research and field expertise to deliver the accuracy and reliability your operations demand.
Leak Detector Technology
Designed for Energy Storage, Transportation, Measuring Stations applications. Delivering reliable performance even in the most demanding environments.
System Configuration
Select your required specifications to configure this production unit
Ultra-compact 12 mm × 12 mm hydrogen leak detector designed for battery safety. Real-time ppm-level detection of hydrogen off-gassing for early warning of thermal events in battery systems.
